苹果手机无线充电器晶振,CC4V-T1A-32.768kHz-9pF-10PPM-TC-QC瑞士微晶

苹果手机无线充电器专用晶振CC4V-T1A-32.768kHz-9pF-10PPM-TC-QC瑞士微晶

另外公司还推出了包括符合通信设备Stratum3及Smallcell专用的7.0x5.0mm及5.0x3.2mmSMD型TCXO温度补偿石英振荡器,以及次世代小型化SMD型VCXO可变电压控制石英振荡器等产品,均可充分供应高速网络与通信设备市场所需.作为本土供应商的代表介绍说,瑞士微晶晶体随着便携式电子设备薄型化的设计趋势,晶振产品在小尺寸开发上要求能够实现从直插到贴片的各种尺寸.另外针对不同的应用环境,也要求晶振产品能够满足更宽的工作温度范围.

苹果手机无线充电器晶振,CC4V-T1A-32.768kHz-9pF-10PPM-TC-QC瑞士微晶

制造商零件编号	制造商	描述	产品类型	容差
CC7V-T1A-32.768kHz-9pF-100PPM-TA-QC	MicroCrystal	晶体32.768kHz9.0pF+/-100PPM-40/+85C	Crystals	100PPM
CC7V-T1A-32.768kHz-9pF-10PPM-TA-QC	MicroCrystal	晶体32.768kHz9.0pF+/-10PPM-40/+85C	Crystals	10PPM
CM7V-T1A-Low-ESR-32.768k-7pF-10-TB-QA	MicroCrystal	晶体32.768kHz7.0pF+/-10PPMLOWESR	Crystals	10PPM
CC7V-T1A-100.000kHz-9pF-100PPM-TA-QC	MicroCrystal	晶体100.000kHz9.0pF+/-100PPM-40/+85C	Crystals	100PPM
CM7V-T1A-32.768kHz-9pF-100PPM-TA-QC	MicroCrystal	晶体32.768kHz9.0pF+/-100PPM-40/+85C	Crystals	100PPM
CM7V-T1A-32.768kHz-12.5pF-100PPM-TB-QC	MicroCrystal	晶体32.768kHz12.5pF100PPM-40/+125C	Crystals	100PPM
CM7V-T1A-Low-ESR-32.768k-9pF-20-TB-QA	MicroCrystal	晶体32.768kHz9.0pF+/-20PPMLOWESR	Crystals	20PPM
CC7V-T1A-32.768k-9pF-20PPM-TB-QA	MicroCrystal	晶体32.768kHz9.0pF+/-20PPMAEC-Q200	Crystals	20PPM
CC7V-T1A-32.768kHz-7pF-10PPM-TA-QC	MicroCrystal	晶体32.768kHz7.0pF+/-10PPM-40/+85C	Crystals	10PPM
CM7V-T1A-32.768k-9pF-100PPM-TC-QA	MicroCrystal	晶体32.768kHz9.0pF+/-100PPMAEC-Q200	Crystals	100PPM
CC4V-T1A-32.768kHz-6pF-20PPM-TA-QC	MicroCrystal	晶体32.768kHz6.0pF+/-20PPM-40/+85C	Crystals	20PPM
CM8V-T1A-32.768kHz-9pF-100PPM-TA-QC	MicroCrystal	晶体32.768kHz9.0pF+/-100PPM-40/+85C	Crystals	100PPM
CC5V-T1A-32.768kHz-6pF-20PPM-TA-QC	MicroCrystal	晶体32.768kHz6.0pF+/-20PPM-40/+85C	Crystals	20PPM
CM8V-T1A-100.000kHz-9pF-100PPM-TA-QC	MicroCrystal	晶体100.000kHz9.0pF+/-100PPM-40/+85C	Crystals	100PPM
CM7V-T1A-32.768k-6pF-20PPM-TB-QA	MicroCrystal	晶体32.768kHz6.0pF+/-20PPMAEC-Q200	Crystals	20PPM
MS1V-T1K-32.768kHz-12.5pF-10PPM-TA-QC-Au	MicroCrystal	晶体32.768kHz12.5pF+/-10PPM-40/+85C	Crystals	10PPM
OV-7605-C8-32.768kHz-20PPM-TA-QC	MicroCrystal	标准时钟振荡器32.768kHz+/-20PPM-40/+85C	ClockOscillators
CC1V-T1A-1.8432MHz-10pF-500PPM-TC-QC	MicroCrystal	晶体1.8432MHz10.0pF500PPM-55/+125C	Crystals	500PPM
OM-7604-C7-32.768kHz-20PPM-TB-QC	MicroCrystal	标准时钟振荡器32.768kHz+/-20PPM-40/+125C	ClockOscillators
CC4V-T1A-32.768k-9pF-20PPM-TC-QA	MicroCrystal	晶体32.768kHz9.0pF+/-20PPMAEC-Q200	Crystals	20PPM
MS1V-T1K-32.768kHz-6pF-10PPM-TA-QC-Au	MicroCrystal	晶体32.768kHz6.0pF+/-10PPM-40/+85C	Crystals	10PPM
OV-7604-C7-32.768k-10PPM-TB-QA	MicroCrystal	标准时钟振荡器32.768kHz+/-10PPM-40/+125CAEC-Q200	ClockOscillators
OV-7604-C7-32.768k-20PPM-TA-QA	MicroCrystal	标准时钟振荡器32.768kHz+/-20PPM-40/+85C	ClockOscillators
CC4V-T1A-1.000MHz-10pF-100PPM-TA-QC	MicroCrystal	晶体1.000MHz10.0pF+/-100PPM-40/+85C	Crystals	100PPM
CC4V-T1A-153.600kHz-9pF-30PPM-TA-QC	MicroCrystal	晶体153.600kHz9.0pF+/-30PPM-40/+85C	Crystals	30PPM
CC1V-T1A-307.20kHz-4pF-100PPM-TC-QC	MicroCrystal	晶体307.200kHz4.0pF100PPM-55/+125C	Crystals	100PPM
CC1V-T1A-1.8432MHz-10pF-100PPM-TA-QC	MicroCrystal	晶体1.8432MHz10.0pF+/-100PPM-40/+85C	Crystals	100PPM
CC1V-T1A-1.8432MHz-10pF-100PPM-TC-QC	MicroCrystal	晶体1.8432MHz10.0pF100PPM-55/+125C	Crystals	100PPM
CC4V-T1A-40.000kHz-12.5pF-20PPM-TA-QC	MicroCrystal	晶体40.0000kHz12.5pF+/-20PPM-40/+85C	Crystals	20PPM
CC4V-T1A-32.768k-12.5pF-20PPM-TB-QA	MicroCrystal	晶体32.768kHz12.5pF+/-20PPMAEC-Q200	Crystals	20PPM
CC4V-T1A-32.768k-12.5pF-20PPM-TC-QA	MicroCrystal	晶体32.768kHz12.5pF+/-20PPMAEC-Q200	Crystals	20PPM
CC4V-T1A-32.768kHz-9pF-10PPM-TC-QC	MicroCrystal	晶体32.768kHz9.0pF+/-10PPM-55/+125C	Crystals	10PPM
CC1V-T1A-32.768kHz-9pF-100PPM-TA-QC	MicroCrystal	晶体32.768kHz9.0pF+/-100PPM-40/+85C	Crystals	100PPM
CC1V-T1A-32.768kHz-9pF-20PPM-TA-QC	MicroCrystal	晶体32.768kHz9.0pF+/-20PPM-40/+85C	Crystals	20PPM
CC1V-T1A-1.8432MHz-10pF-500PPM-TA-QC	MicroCrystal	晶体1.8432MHz10.0pF+/-500PPM-40/+85C	Crystals	500PPM

如工业级应用要求的-40～85度、汽车级应用要求的-40～125度；军品级应用要求的-55～125度.同时产品的输出形式也要多样化,其中包括SINE、TTL、CMOS、LVPECL、LVDS、HCSL等.瑞士微晶目前推出的产品规格最小可达到2520,同2016(2.0x1.6mm)也正在加紧研发之中.据介绍目前产能主要以石英晶体振荡器为主,贴片晶体和振荡器合计产能约为8kk/月,其中包括汽车级、军品级、工业级.苹果手机无线充电器晶振,CC4V-T1A-32.768kHz-9pF-10PPM-TC-QC瑞士微晶
