TZKTADSANF-26.000000有源晶振,2016温补晶体振荡器

TZKTADSANF-26.000000有源晶振,2016温补晶体振荡器，编码：TZKTADSANF-26.000000，型号：TZ，工作温度：-30°C ~ 85°C，尺寸：2.0mm*1.6mm，频率：26MHz，精度：±500ppb，电压：1.8V，电流：1.5mA，温补有源晶振，进口石英晶体振荡器，OSC石英晶振，2016贴片晶振，温补晶体振荡器，高精度温补晶振 ，典型的2.0 x 1.6 x 0.7 mm陶瓷SMD封装，用于自动装配，小巧轻便 ，具有低抖动，低差损，低相噪，低相控，高性能等特点，产品广泛应用于工业设备，智能手机，平板电脑，无线通信，智能家具家电等应用。

TZKTADSANF-26.000000有源晶振,2016温补晶体振荡器，编码：TZKTADSANF-26.000000，型号：TZ，工作温度：-30°C ~ 85°C，尺寸：2.0mm*1.6mm，频率：26MHz，精度：±500ppb，电压：1.8V，电流：1.5mA，温补有源晶振，进口石英晶体振荡器，OSC石英晶振，2016贴片晶振，温补晶体振荡器，高精度温补晶振 ，典型的2.0 x 1.6 x 0.7 mm陶瓷SMD封装，用于自动装配，小巧轻便 ，具有低抖动，低差损，低相噪，低相控，高性能等特点，产品广泛应用于工业设备，智能手机，平板电脑，无线通信，智能家具家电等应用。

TZKTADSANF-26.000000有源晶振,2016温补晶体振荡器，参数表

Mfr Part #	石英晶振2016	Series	Type	Frequency	Output	Voltage - Supply	Frequency Stability
TZKTADSANF-26.000000	Taitien	TZ	TCXO	26 MHz	Clipped Sine Wave	1.8V	±500ppb
TYETBCSANF-32.000000	Taitien	TY	TCXO	32 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±1ppm
TYETBLSANF-40.000000	Taitien	TY	TCXO	40 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±1ppm
TYEAPLSANF-40.000000	Taitien	TY	VCTCXO	40 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±1.5ppm
TYETACSANF-26.000000	Taitien	TY	TCXO	26 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±500ppb
TYEAACSANF-38.400000	Taitien	TY	VCTCXO	38.4 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±500ppb
TYETBLSANF-38.400000	Taitien	TY	TCXO	38.4 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±1ppm
TYETBCSANF-50.000000	Taitien	TY	TCXO	50 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±1ppm
TYETACSANF-32.000000	Taitien	TY	TCXO	32 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±500ppb
TYETACSANF-20.000000	Taitien	TY	TCXO	20 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±500ppb
TYKTCCSANF-38.400000	Taitien	TY	TCXO	38.4 MHz	Clipped Sine Wave	1.8V	±2ppm
TYETBCSANF-20.000000	Taitien	TY	TCXO	20 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±1ppm
TZETADSANF-38.400000	Taitien	TZ	TCXO	38.4 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±500ppb
TYETACSANF-19.200000	Taitien	TY	TCXO	19.2 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±500ppb
TZETADSANF-26.000000	Taitien	TZ	TCXO	26 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±500ppb
TZETADSANF-19.200000	Taitien	TZ	TCXO	19.2 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±500ppb
TZKTADSANF-38.400000	Taitien	TZ	TCXO	38.4 MHz	Clipped Sine Wave	1.8V	±500ppb
TZETADSAGF-26.000000	Taitien	TZ	TCXO	26 MHz	Clipped Sine Wave	3.3V	±500ppb
TZJTADSANF-19.200000	Taitien	TZ	TCXO	19.2 MHz	Clipped Sine Wave	2.5V	±500ppb
TYJABCSANF-16.367667	Taitien	TY	VCTCXO	16.367667 MHz	Clipped Sine Wave	2.5V	±1ppm
TYJADCSANF-16.367667	Taitien	TY	VCTCXO	16.367667 MHz	Clipped Sine Wave	2.5V	±2.5ppm
TYEAPCSANF-16.367667	Taitien	TY	VCTCXO	16.367667 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±1.5ppm
TYKTDLSANF-50.000000	Taitien	TY	TCXO	50 MHz	Clipped Sine Wave	1.8V	±2.5ppm
TYKTBCSANF-26.000000	Taitien	TY	TCXO	26 MHz	Clipped Sine Wave	1.8V	±1ppm
TZETADSAGF-38.400000	Taitien	TZ	TCXO	38.4 MHz	Clipped Sine Wave	3.3V	±500ppb
TYETACSANF-16.367667	Taitien	TY	TCXO	16.367667 MHz	Clipped Sine Wave	2.8V ~ 3.3V	±500ppb
TYKTALSANF-26.000000	Taitien	TY	TCXO	26 MHz	Clipped Sine Wave	1.8V	±500ppb
