JH53-50MHZ有源差分晶体,Connor-Winfield石英晶体振荡器，编码：JH53-50MHZ，型号：H53系列晶振，工作温度：0°C ~ 70°C，尺寸：12.7*12.7mm，频率：50MHz，电压：5V，精度：±100ppm，输出方式：HCMOS，康纳温菲尔德晶振，差分输出振荡器，差分贴片晶体，有源晶振SPXO，差分晶振常用于高精度的时钟应用，如通信设备、数据存储器和精密仪器等。它的优点包括低相位噪声，低抖动和高频率稳定性，能够满足一些对时钟信号质量要求较高的应用场景。差分晶振是一种常见的电子元件，可用于许多应用领域。
JH53-50MHZ有源差分晶体,Connor-Winfield石英晶体振荡器，参数表
| 编码 | JH53-50MHZ |
| 品牌 | Connor-Winfield |
| 型号 | H53 |
| 频率 | 50MHz |
| 输出方式 |
HCMOS |
| 电压 | 5V |
| 精度 | ±100ppm |
| 工作温度 | 0°C ~ 70°C |
| Manufacturer Part Number原厂代码 | 壹兆晶振厂家 | Series型号 | Type 类型 | Frequency 频率 | Output 输出 | Voltage - Supply电压 | Frequency Stability频率稳定度 | Operating Temperature 工作温度 |
| HSM613-060.0M | Connor-Winfield | HSM6 | XO (Standard) | 60MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-060.0M | Connor-Winfield | HSM6 | XO (Standard) | 60MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-060.0M | Connor-Winfield | HSM6 | XO (Standard) | 60MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-020.0M | Connor-Winfield | HSM6 | XO (Standard) | 20MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-020.0M | Connor-Winfield | HSM6 | XO (Standard) | 20MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-020.0M | Connor-Winfield | HSM6 | XO (Standard) | 20MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-049.152M | Connor-Winfield | HSM6 | XO (Standard) | 49.152MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-049.152M | Connor-Winfield | HSM6 | XO (Standard) | 49.152MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-049.152M | Connor-Winfield | HSM6 | XO (Standard) | 49.152MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-050.0M | Connor-Winfield | HSM6 | XO (Standard) | 50MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-050.0M | Connor-Winfield | HSM6 | XO (Standard) | 50MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-050.0M | Connor-Winfield | HSM6 | XO (Standard) | 50MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-024.576M | Connor-Winfield | HSM6 | XO (Standard) | 24.576MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-024.576M | Connor-Winfield | HSM6 | XO (Standard) | 24.576MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-024.576M | Connor-Winfield | HSM6 | XO (Standard) | 24.576MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-078.125M | Connor-Winfield | HSM6 | XO (Standard) | 78.125MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-078.125M | Connor-Winfield | HSM6 | XO (Standard) | 78.125MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-078.125M | Connor-Winfield | HSM6 | XO (Standard) | 78.125MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-098.304M | Connor-Winfield | HSM6 | XO (Standard) | 98.304MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-098.304M | Connor-Winfield | HSM6 | XO (Standard) | 98.304MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-098.304M | Connor-Winfield | HSM6 | XO (Standard) | 98.304MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
| HSM613-114.285M | Connor-Winfield | HSM6 | XO (Standard) | 114.285MHz | HCMOS | 3.3V | ±25ppm | -40°C ~ 85°C |
